200L Steel Drum Uses in Various Industries

Technical Specifications

Detailed technical information and product specifications

Basic Specifications

Capacity 210L

Material cold_rolled_steel

Wall Thickness 1.0mm / 1.2mm

Available Shapes

round closed_top

Printing Options varnish

Dimensions

Diameter 571.5mm

Height 885mm

Certifications & Standards

ISO9001_2015

food_grade

un_rated

Product Details

Product Overview

The 200L steel drum represents the gold standard in industrial bulk packaging, offering unmatched durability and versatility for liquid and semi-solid products across global supply chains. Manufactured from cold-rolled steel with advanced protective coatings, our UN-certified drums provide secure containment for everything from hazardous chemicals to food-grade products, meeting the most demanding industrial requirements.

Key Features & Benefits

🛡️ Superior Protection & Safety

Leak-proof Construction: Double-seamed top and bottom with reinforced rolling hoops
UN Certification: Compliant with international hazardous material transport regulations
Corrosion Resistance: Multiple interior coating options for maximum product compatibility
Tamper-evident Closures: Optional security features for high-value products

🏭 Industrial-Grade Durability

Heavy-Duty Construction: 1.2mm cold-rolled steel body withstands rough handling
Stackable Design: Reinforced structure allows safe stacking up to 3 drums high
Weather Resistance: Suitable for outdoor storage in various climate conditions
Long Service Life: Reusable design with proper cleaning and maintenance

🔧 User-Friendly Design

Standardized Dimensions: Compatible with global handling and storage systems
Multiple Opening Options: Tight head (closed) or open head with removable lids
Integrated Rolling Hoops: Facilitates easy movement with drum trucks
Uniform Fill/Empty Ports: Standard 2″ NPS and 3/4″ vent openings

Technical Specifications

Parameter	Specification
Capacity	200 Liters (55 US Gallons)
Material	Cold-rolled steel, various thickness options
Dimensions	Standard: 880mm height × 585mm diameter
Empty Weight	17-21kg (depending on configuration)
Lid Types	Tight head (closed), open head (full removable)
Interior Coatings	Epoxy, phenolic, or uncoated
Exterior Finish	Painted, galvanized, or printed options
Load Capacity	Stacking strength up to 3 high when filled
Certifications	UN certified, ISO 9001:2015 manufacturing

Applications Across Industries

Chemical Industry

Paints & Coatings: Solvent-based and water-based products
Adhesives & Resins: Industrial adhesives, epoxy resins
Chemical Intermediates: Acids, alkalis, solvents (with appropriate linings)
Cleaning Compounds: Industrial cleaners, detergents

Food & Beverage

Edible Oils: Vegetable oils, palm oil, specialty oils
Food Additives: Preservatives, flavorings, colorants
Syrups & Concentrates: Beverage bases, fruit concentrates
Food-grade Chemicals: Additives with appropriate FDA-approved linings

Petroleum & Lubricants

Motor Oils: Bulk packaging for blending and distribution
Industrial Lubricants: Hydraulic oils, gear oils, greases
Process Oils: Transformer oils, white oils
Additives: Fuel additives, oil treatment compounds

Pharmaceutical & Cosmetics

Raw Materials: Bulk pharmaceutical ingredients
Cosmetic Bases: Lotions, creams, cosmetic chemicals
Intermediate Products: Chemical compounds for further processing

Specialty Applications

Agricultural Chemicals: Pesticides, herbicides, fertilizers
Construction Materials: Sealants, waterproofing compounds
Marine Products: Boat coatings, marine chemicals

Customization Options

Structural Variations

Open Head Drums: Full removable lid for easy cleaning and filling
Tight Head Drums: Permanent top with standard openings
Reinforced Designs: Extra thickness for specific hazardous materials
Special Openings: Custom bung arrangements and sizes

Protective Coatings

Interior Linings:
- Epoxy phenolic (universal chemical resistance)
- Phenolic (compatible with oils and solvents)
- FDA-approved epoxy (food-grade applications)
Exterior Finishes:
- Painted (standard colors or custom matching)
- Galvanized (superior corrosion resistance)
- Printed (branding, handling instructions, safety labels)

Accessory Options

Closure Systems: Lever locks, bolt rings, flanges
Safety Features: Pressure relief valves

Ordering Information

Service	Details
Minimum Order Quantity	100 units
Sample Availability	Production samples available with lead time
Production Capacity	50,000+ units monthly
Lead Time	15 days for standard orders
Customization	Tooling and setup charges may apply for special designs
